Voice Features

Voice Codecs: G.711, G.723.1, G.726, G.729AB, G.722, VAD, CNG, AEC, PLC, AJB, AGC

Telephony Features

1 VoIP User Account

Direct IP call without

SIP proxy

Call Hold

Call Waiting

Call Transfer

Block Anonymous Calls

Hotline

Redial

2 Speed Dials

Volume Control

Call Mute

Ringtone Selection (via web)

Tone scheme

Integrated Voice Response System

Network FeaturesSIP v1(RFC2543),

v2(RFC3261)

NAT transverse: STUN mode

IP Assignment: Static/DHCP/PPPoE

In-Band DTMF, Out-of-Band DTMF (RFC2833)

SIP Info

Proxy mode and Peer-to-peer

SIP link mode

TFTP/DHCP/PPPoE client

DNS client

NAT/DHCP server

IP PBX System Integratio

Music on Hold

Intercom

Group Paging

Call Pickup

Call Park

Call Forward

DND

Distinctive

Ringing

Dial plan

Dial now

Voicemail

Message Waiting Indication (MWI)

Config, Upgrade and Usage

Configuration: browser/phone /auto-provision/IVR

Auto provision via TFTP/FTP/ HTTP/PnP

Auto provision: firmware configuration, ringtone etc.

Security
QoS: IEEE 802.1p/q tagging (VLAN), Layer 3ToS

Digest authentication using MD5/MD5-sess

Secure configuration file via AES encryption

Admin/user configuration mode

Physical Features

TI TITAN chipset 20 keys including 2 programmable keys 4 feature keys (Mute/Redial/ Transfer/Hold)

1xLEDs for power and status indication
1xRJ45 10/100M Ethernet ports

Phone label for speed dialing numbers

Power adapter: AC 100~240V input and DC 5V/1.2A Output

Power over Ethernet (IEEE 802.3af class 1) optional

Operating humidity: 10~95%

Storage temperature: up to 60 C

Package features

Qty/CTN: 5 PCS

N.W/CTN: 7.87KG

G.W/CTN: 9.00KG

Measurement: 0.073CMB

Carton Meas: 470x287x222MM

Additions Coming Soon

DSCP/802.1pq

HTTPS (Server/Client)

SRTP (RFC3711)

Transport Layer Security (TLS)

Built-in web server (HTTPS
